Lab 6

Part 2

Capacitor: 1microFarad

Potentiometer: 10kΩ

High End:

1/(2*3.14*10*.000001) = 15923.566hz

Low End:

1/(2*3.14*10,000*.000001) = 15.923hz

Low Pass:

High Pass:

Part 3)

(NEED SCHEMATIC)

Part 4)

To increase the filter by +6db/octave, one must add another capacitor and resistor to the circuit. For example, one pole is a 6db/octave filter and a two pole is a 12db/octave filter.
